Ozone in public pools
Maximum water quality
Use of ozone in swimming pools
Ozone is used in public pools as a disinfectant and purifier. Its disinfection power is much higher than that of chlorine, with the advantage that it does not leave residues, does not irritate the skin, eyes, hair, nostrils.
Ozone eliminates chloramines and reduces organochlorine compounds that cause unpleasant tastes and odors for bathers, as well as providing extra dissolved oxygen in the water, which improves comfort during exercise. It manages to reduce the use of chlorine, flocculants and coagulants in your pool by up to 80% and prevents the appearance of isocyanides. In addition, its powerful purifying capacity allows it to improve turbidity, SS, SD, providing more crystalline and pure water.
Ozone is not transported or stored, it is generated on-site and applied instantly. It works automatically and autonomously.
Saves chlorine and chemicals, and provides a health bath
Ozone reduces the consumption of chlorine and chemical products
Ozone is generated in-situ, it does not need to store or transport chemicals.
Ozone does not leave residues, it is respectful with the environment
The system is automated, you do not need manpower to apply it
Problems with the water in the pool?
Advantages of treating your pool with Ozone
Reduces chlorine consumption
Ozone has a much higher disinfection power than chlorine. With an ozone system in your pool, you will have to apply much less chlorine to maintain the required residual in the pool. It will also reduce the consumption of flocculants and coagulants and will reduce the appearance of isocyanates.
Top quality water
Ozone is a powerful water purifier, which reduces the organic and inorganic load through oxidation. By mixing it in the water, it reduces COD, BOD, SS, SD, turbidity, color, taste, odor. In addition, it does not alter the pH, and does not generate waste that must be treated. It provides crystal clear water, which the bather appreciates.
No odors or flavors
Ozone eliminates unpleasant tastes and odors in swimming pools, caused by the formation of organochlorine compounds, resulting from mixing chlorine with organic matter. Providing the swimmer with a unique and pleasant sensation in the bathroom.
Without labor, automatic
The system generates ozone and injects it into the tank automatically, without the need to apply manual labor in the process. The equipment only needs to be connected to the tank to be treated and provide it with a point of light.
No chemical storage
Ozone cannot be transported or stored, it is generated on site, and it is applied instantly, so it is not necessary to store and manage chemical products, it avoids transport and reduces the carbon footprint.
Biocide recognized by the ECHA
Ozone is on the list of biocides by the European Chemical Agency and ZonoSistem has all the necessary legalization documentation to be able to apply ozone in its process.
What type of ozone generator does my public pool need?
Below, we show you the ranges of ozone generators available for public pools.
 |  | |
|---|---|---|
| Recommendations | Model HIDRO V GZO 20 For pools with volume < 800 m3 With automatic control | Model HIDRO V GZO 40 For pools with volume < 1.600 m3 With automatic control |
| Equipment Included | Air Cooled Generator.
With Compressor. With Oxygen Concentrator. With Refrigeration Dryer. With Pump and Venturi. With Automatic Power Control. With Recipe Manager by PLC. With Redox Meter. With Leak Sensor. | Air Cooled Generator. With Compressor. With Oxygen Concentrator. With Refrigeration Dryer. With Pump and Venturi. With Automatic Power Control. With Recipe Manager by PLC. With Redox Meter. With Leak Sensor. |
| Optional Equipment | Dissolved Ozone meter ppm. Remote Control, PC or Mobile | Dissolved Ozone meter ppm. Remote Control, PC or Mobile. |
| Ozone concentration | 65 gO3/m3 | 65 gO3/m3 |
3. How much ozone do I need?
The calculation of the ozone dose to be applied to a swimming pool for collective use will depend on several factors. The main factors are related to the use of the pool ( number of users ), type of biocide used, current state of the water treatment plant, size of the pool, water temperature, etc... Even so we can estimate a standard dose that will surely be very positive and will obtain important benefits, this dose of ozone is estimated around 1g/h per 40 m3 of water.
With this rate applied in the compensation basin, by means of a HIDRO V system, organic matter reductions will be produced and disinfection processes will be initiated, avoiding the generation of chloramines and causing a strong reduction of the necessary chlorine. In addition, filter washings will be reduced, leading to a significant reduction in water consumption.
How is it installed?
The installation is very simple. We only have to recirculate the water from the recirculation vessel, using the HIDRO V compact plant. In the following diagram you can see the recommended electrical connections.
As an accepted improvement to this hydraulic diagram, a small modification can be made to the suction of the HIDRO V plant, taking the suction water directly from the filtered water pipe, thus avoiding possible clogging of the recirculation pump caused by corks, hair and dirt.
Notes: There are a multitude of installation options depending on the objectives to be achieved. Consult with ZonoSistem's pool ozone experts.
Examples of ozone installations in public swimming pools
Ozone for swimming pool, Murcia. Spain
Ozone for indoor pool. Sherry, Spain.
Ozone for pool in basement, Spain.
Ozone for swimming pool and gym, Spain
Ozone for swimming pool, Canary Islands. Spain.
Ozone for swimming pool in hotel, Spain
